Veratron VMH 35 screen

VERATRON VMH 35: The Ultimate All-in-One Marine Display

Elevate your vessel´s dashboard with the VERATRON VMH 35, the compact and powerful all-in-one instrument screen designed for the modern mariner. This sophisticated device acts as the intelligent heart of your boat´s information system, consolidating a vast array of data into a single, crystal-clear display. Say goodbye to a cluttered console of single-function gauges and welcome a new era of centralized control and unparalleled readability. The VMH 35 is engineered to be the perfect solution for both new installations and classic vessel refits, seamlessly bridging the gap between traditional analog sensors and modern NMEA 2000 digital networks.

Experience superior situational awareness with a display that puts critical information right where you need it. Whether you are monitoring engine performance, checking fuel levels, tracking your battery status, or navigating with GPS data, the VMH 35 presents it all with exceptional clarity. Its intuitive interface and highly configurable layouts allow you to customize the data screens to match your specific needs, ensuring you see what matters most to you at a glance. Built for the harsh marine environment, this robust instrument is fully sealed and waterproof, guaranteeing reliable performance in any weather, from calm coastal cruises to challenging offshore passages.

Key Benefits:

* Centralized Data Hub: Consolidates all your critical vessel data—including engine, navigation, tank levels, and battery status—onto one dynamic screen, reducing dashboard clutter and improving oversight.
* Exceptional Visibility: The optically bonded display provides outstanding, glare-free readability in all light conditions, including direct, bright sunlight, ensuring you never miss a crucial reading.
* Hybrid Integration Master: Uniquely equipped with both NMEA 2000 connectivity and direct analog inputs, making it the ideal upgrade for retrofitting older boats, allowing you to integrate existing analog sensors into a modern digital system.
* Effortless Installation: Designed to fit a standard 85 mm (3-3/8") instrument cutout, allowing for a quick and simple drop-in replacement of your old gauges.
* Integrated Navigation: A built-in high-performance GPS receiver provides essential data like Speed Over Ground (SOG) and Course Over Ground (COG) without the need for an external antenna.

Main Features:

The core of this device is its brilliant Screens technology. The centerpiece is a vibrant 3.5-inch IPS TFT screen that delivers rich color and wide viewing angles. The mineral glass front is optically bonded to the display, preventing condensation and maximizing contrast. The VMH 35 features a powerful microprocessor capable of displaying data from NMEA 2000, J1939, and analog inputs simultaneously. It boasts easy-to-use six-button touch keypads for seamless navigation through customizable data pages. Its robust housing is fully sealed and waterproof to IPX7 standards on both the front and back for maximum durability.

Technical Specifications:

* Resolution: 320x240 pixels
* Nominal Voltage: 12 V
* Operating Voltage: 9 V - 16 V
* Current Consumption: ≤ 150 mA (max)
* Protection Rating: IPX7 protection class (front and rear)
* Dimensions: 100 mm outer diameter, 85 mm installation cutout
* Connectivity: 1x NMEA 2000 M12 5-pin, 1x 8-pin Tyco/Hirschmann MQS Connector
* Inputs: 2x Resistive (0-400 Ω), 1x Frequency (0-4 kHz)
* GPS/GNSS: Integrated 10 Hz GPS/GLONASS/Galileo receiver
* Lens: Anti-glare mineral glass, optically bonded
* Bezel: Black brushed stainless steel (AISI 316)
