Ergon CF Allroad Pro Carbon Setback seatpost

Answer of Charles

It will dampen some road vibration but not smooth out any bumps like you probably require. There is barely 2cm of deflection on the hardest bumps.

It will dampen some road vibration but not smooth out any bumps like you probably require. There is barely 2cm of deflection on the hardest bumps.

Answer of Aaron (Addy)

The seatpost fits the standard round 27.2mm diameter seatpost hole. It’s the most common round road bike seatpost size

The seatpost fits the standard round 27.2mm diameter seatpost hole. It’s the most common round road bike seatpost size

Answer of Aliaksandr

It's not the same seatpost as on your Berria, but yes, it will fit the frame

It's not the same seatpost as on your Berria, but yes, it will fit the frame

Answer of Adam

You should just set your saddle where you would normally set your saddle. The fractions of a second when it flexes don't matter, but you should accommodate saddle height for a little sag.

You should just set your saddle where you would normally set your saddle. The fractions of a second when it flexes don't matter, but you should accommodate saddle height for a little sag.

Answer of Adam

Cool ride! Normal rattling on a trail is fine, but manufacturer specs say these will NOT take seated drops of more than 1 foot. There is also a weight limit on the seat post. That said, I've been using on my gravel bike for 3 years now and it's great.

Cool ride! Normal rattling on a trail is fine, but manufacturer specs say these will NOT take seated drops of more than 1 foot. There is also a weight limit on the seat post. That said, I've been using on my gravel bike for 3 years now and it's great.

Answer of Adam

You'll get 20-25mm travel with this seatpost. Definitely less cushioning than a conventional suspension post. However, it is also significantly lighter than a damped suspension post and requires no maintenance other than periodic cleaning so that dirt doesn't get between the suspension "leaves" and cause wear.

You'll get 20-25mm travel with this seatpost. Definitely less cushioning than a conventional suspension post. However, it is also significantly lighter than a damped suspension post and requires no maintenance other than periodic cleaning so that dirt doesn't get between the suspension "leaves" and cause wear.

Answer of Owen

I see you are asking how the flex compares to a suspension seatpost. The Ergon CF Allroad Pro Carbon Setback is a suspension seatpost that uses carbon leaf springs to reduce common road cycling discomforts. The Two Flexible Vcls Leaf Springs Are Made Of The Highest Quality Carbon Fiber Composites. This Construction Reduces Road Shock And Absorbs Vibrations. This Results In Less Overall Fatigue And You Can Continue To Put Power To The Pedals.

I see you are asking how the flex compares to a suspension seatpost. The Ergon CF Allroad Pro Carbon Setback is a suspension seatpost that uses carbon leaf springs to reduce common road cycling discomforts. The Two Flexible Vcls Leaf Springs Are Made Of The Highest Quality Carbon Fiber Composites. This Construction Reduces Road Shock And Absorbs Vibrations. This Results In Less Overall Fatigue And You Can Continue To Put Power To The Pedals.

Answer of Adam

27.2 mm diameter 353 mm length ***152 mm of seat post at maximum insertion 255 mm of seat post at minimum insertion

27.2 mm diameter 353 mm length ***152 mm of seat post at maximum insertion 255 mm of seat post at minimum insertion

Answer of Owen

Hi! I see that you have an Ortlieb seat-pack, which says that they're not to be installed on carbon fiber seat posts. So, A) No, it should not be installed on this seat post, because B) it is made of carbon fiber. Good luck and safe riding!

Hi! I see that you have an Ortlieb seat-pack, which says that they're not to be installed on carbon fiber seat posts. So, A) No, it should not be installed on this seat post, because B) it is made of carbon fiber. Good luck and safe riding!

Answer of Adam

Per manufacturer´s spec, maximum rider weight is 90kg/220lbs. There is no minimum weight, although the lighter you are, the less it will flex.

Per manufacturer´s spec, maximum rider weight is 90kg/220lbs. There is no minimum weight, although the lighter you are, the less it will flex.

Answer of Andrew

This is the best seat-post I've had. it really does damp the worst effects of poor road surfaces and I see no reason why this effect would be affected by a lower rider weight (I'm over 90kg!).

This is the best seat-post I've had. it really does damp the worst effects of poor road surfaces and I see no reason why this effect would be affected by a lower rider weight (I'm over 90kg!).

Answer of Brockdorf Melchar &

This seat post fits my Specialized Diverge with a standard round hole. It does not fit my wife´s BMC with an oval hole.

This seat post fits my Specialized Diverge with a standard round hole. It does not fit my wife´s BMC with an oval hole.

Answer of Damien

Firstly, check your current stem diameter, m on your Giant Révolte, either it´s 27.2mm or 30.6mm, but probably 27.2mm. Next, measure the extended length of your current seat post. From the saddle mounting rails to the seat post clamp on the frame, there needs to be a minimum of 140mm of output, from what I measure. Then there´s a 100kg weight limit on the seat post, which is huge since you´re distributing your weight between the saddle, pedals and handlebars. In my opinion your bike is completely compatible with this seat post. Please note that this is a carbon seat post and that you will need to use the special paste supplied with it for assembly, and not exceed the tightening torque.

Premièrement, vérifiez le diamètre de votre tige actuelle,m sur votre Giant Révolte, à savoir soit c´est 27,2mm ou 30,6mm, mais probablement 27,2mm. Ensuite, mesurez la longueur sortie de votre tige de selle actuelle. Depuis les rails de fixation de la selle jusqu´au collier de serrage de la tige de selle sur le cadre, il faut un minimum de 140mm de sortie, de ce que je mesure. Ensuite il y a une limite de poids de 100kg sur la tige de selle, ce qui est énorme puisque vous répartissez votre poids entre la selle, les pédales et le guidon. A mon avis votre vélo est tout à fait compatible avec cette tige de selle. A noter que c´est une tige de selle carbone et qu´il vous faudra utiliser la pâte spéciale fournie avec pour le montage, et ne pas dépasser le couple de serrage.

Answer of Donald

Hello, I have the Ergon seat post installed on my 2022 Specialized Diverge and it’s working out very well. I know it’s designed for bikes with a 27.2 mm seat post, otherwise I’m not aware of any reason it would not be compatible with your bike. Cheers

Hello, I have the Ergon seat post installed on my 2022 Specialized Diverge and it’s working out very well. I know it’s designed for bikes with a 27.2 mm seat post, otherwise I’m not aware of any reason it would not be compatible with your bike. Cheers

Answer of Donald

Hello, It appears the seat post will be very close to your limit, if not a bit short. Because of it’s unique design, the bottom of the seat post to the minimum insertion line measures 11.0 CM or 10.6 CM depending on where the measurement is taken. If I measure from the limit line to the center of the front saddle mounting bolt, I come up with 23.5 CM. This was a question I should have asked before purchasing the seat post because I’m quite tall and to get the necessary saddle height, I needed to raise it beyond the limit by approximately the same amount as you would need to, and combined with the fact that I am right at the recommended weight limit meant that my wife acquired a very nice Ergon seat post…and she loves it! I hope this was helpful. Cheers

Hello, It appears the seat post will be very close to your limit, if not a bit short. Because of it’s unique design, the bottom of the seat post to the minimum insertion line measures 11.0 CM or 10.6 CM depending on where the measurement is taken. If I measure from the limit line to the center of the front saddle mounting bolt, I come up with 23.5 CM. This was a question I should have asked before purchasing the seat post because I’m quite tall and to get the necessary saddle height, I needed to raise it beyond the limit by approximately the same amount as you would need to, and combined with the fact that I am right at the recommended weight limit meant that my wife acquired a very nice Ergon seat post…and she loves it! I hope this was helpful. Cheers

Answer of Owen

Correct, there is a weight limit of 100kg (220lbs).

Correct, there is a weight limit of 100kg (220lbs).

Answer of Donald

That’s true, there is a 100kg limit on the seat post. I am right about at the limit but it turns out the seat post isn’t long enough for me so my wife (who fortunately is WELL under the limit) now has it on her gravel bike…and loves it!

That’s true, there is a 100kg limit on the seat post. I am right about at the limit but it turns out the seat post isn’t long enough for me so my wife (who fortunately is WELL under the limit) now has it on her gravel bike…and loves it!

Answer of James

Yes, according to Ergon's website the seat post has a weight limit of 100 KG (220 LBS).

Yes, according to Ergon's website the seat post has a weight limit of 100 KG (220 LBS).

Answer of Owen

One is straight and has no setback. The other is curced and has a setback. This is the same as any other straight or setback seatpost.

One is straight and has no setback. The other is curced and has a setback. This is the same as any other straight or setback seatpost.

Answer of Guido

Better vibration absorption. I use it on a gravel and in addition to making the bike more comfortable, it allows me to increase the saddle-handlebar distance.

Migliore assorbimento delle vibrazioni. Lo uso su una gravel ed oltre a rendere la bici piu´ confortevole, permette di incrementare la distanza sella-manubrio.

Answer of Owen

The post diameter is 27.2mm. If your bike has a seat post now with a 27.2 mm post diameter, then this post will work.

The post diameter is 27.2mm. If your bike has a seat post now with a 27.2 mm post diameter, then this post will work.
