Features of Tp-link TL-SG2016P

Product description of Tp-link TL-SG2016P switch

Description summary

Upgrade your network with the TP-Link TL-SG2016P, a powerful and versatile L2/L3/L4 managed switch. It provides 16 Gigabit Ethernet ports, including 8 PoE+ ports with a generous 120W total power budget, perfect for powering IP cameras, VoIP phones, and access points. Take control with robust security features, advanced QoS, and extensive VLAN support. Manage your network effortlessly through the web interface, CLI, or the cloud. Its silent, fanless operation and durable metal housing make it a reliable choice for any business. EU Plug

EU Plug.

TP-Link TL-SG2016P.

Switch layer:L2/L3/L4.

Basic RJ-45 Ethernet switching type ports:Gigabit Ethernet (10/100/1000), Number of basic RJ-45 Ethernet switching ports:16.

MAC address table:8000 entries.

Network standards:IEEE 802.11w, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1x, IEEE 802.3ab, IEEE.

DC input voltage:53.5 V.

Electrical connector:DC input socket.

Power over Ethernet (PoE).

Specifications:

-Quantity of basic RJ-45 Ethernet switching ports:16.

-Basic RJ-45 Ethernet switching type ports:Gigabit Ethernet (10/100/1000).

-Electrical connector:DC input socket.

-Width:286 mm.

-Depth:111.7 mm.

-Height:25.4 mm.

-Power consumption (max):146.5 W.

-DC input voltage:53.5 V.

-Input current:1.31 A.

-Power source:DC/PoE.

-Operating temperature range:0 -40 °C.

-Relative operating humidity:10 -90%.

-Storage temperature range:-40 -70 °C.

-Storage relative humidity:5 -90%.

-Heat dissipation:499.98 BTU/h.

-Supported network protocols:ICMP, TCPv6, UDPv6, Ping6, Tracert6, Telnet (v6), TFTP, TCP/UDP, DSCP/IP, SSLv3, TLS 1.2.

-IPv4 and IPv6 functions:Dual stack IPv4/IPv6.

-GARP VLAN Registration Protocol (GVRP):Yes.

-Network standards:IEEE 802.11w, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3x.

-Support 10G:No.

-Auto MDI / MDI-X:Yes.

-Auto-negotiation:Yes.

-Copper Ethernet cabling.

Technology:10BASE-T, 100BASE-TX, 1000BASE-T.

-Port mirroring:Yes.

-Flow control support:Yes.

-Adding links:Yes.

-Limit rate:Yes.

-VLAN Support:Yes.

-Virtual LAN functions:Multicast VLAN, Tagged VLAN, Voice VLAN.

-Supported cable types:Cat3, Cat4, Cat5, Cat5e.

-Storm transmission control:Yes.

-Number of VLANs:4000.

-Spanning tree protocol:Yes.

-Ethernet LAN, data transfer speed:10,100,1000 Mbit/s.

-MAC address table:8000 entries.

-Jumbo Frames, support:Yes.

-Jumbo frames:9000.

-Number of queues:8.

-Package buffer:4.1 MB.

Performance:16 Gbit/s.

-User manual:Yes.

-DHCP.

Features:

DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 snooping.

-Access Control List (ACL):Yes.

-IGMP:Yes.

-Supported security algorithms:EAP-MD5, HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSL/TLS.

-MAC, address filter:Yes.

-SSH/SSL support:Yes.

-BPDU protection and filtering:Yes.

-IP-MAC port binding:Yes.

-Authentication:Guest VLAN, MAC-based authentication, Port-based authentication.

-Queue scheduling algorithms:SP, Weighted Round Robin (WRR).

-MAC address entries:Dynamic MAC address entries, Static MAC address entries.

-Quality of service (QoS) support:Yes.

-Web-based administration:Yes.

-Switch layer:L2/L3/L4.

-ARP inspection:Yes.

-Registration of events in the system:Yes.

-MIB, support:RFC1213, RFC1493, RFC2674, RFC2620, RFC2618, RFC2925, RFC1757.

-Location settings configuration (CLI):Yes.

-Managed through the cloud:Yes.

-Product color:Black.

-LED Indicators:PoE, Power, System.

Certification:CE, FCC, RoHS.

-Housing material:Metal.

-PoE:Yes.

-Power over Ethernet (PoE) Budget:120 W.

-Power over Ethernet Plus (PoE +) Number of ports:8.

-Firmware upgradeable:Yes.

-Without fan:Yes.

-Minimum system requirements:Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7/8/10/11, MAC OS, NetWare, UNIX, Linux.

-Multicast, support:Yes.

-Multicast Throughput Intrusion (MLD):MLD v1, MLD v2.
